FireTech
Instinct Lightbar
Size:
Size
LED Colors:
LED Colors
Quantity:
Choose options
Size:
Size
LED Colors:
LED Colors
Quantity:
Size:
Size
LED Colors:
LED Colors
Quantity:
Key Features & Capabilities
- Software-Defined Performance: Fully user-programmable with customizable flash patterns, modes, and intensity. Syncs seamlessly with virtually any siren controller, including the new Redline Hot Zone controller.
- Multi-Color Configurations: Front – Red/Blue/White | Rear – Red/Blue/Amber. Utility versions available with Amber/White + integrated brake, tail, and turn signals.
- Built-In Traffic Director: Arrow patterns right out of the box, no extra modules required.
- Smart Auto-Dimming: Dual light sensors automatically switch to night mode. Manual low-intensity dimming prevents blinding traffic while delivering full power when you need it.
- Takedown & Steady-Burn Modes: Activate any white LEDs as steady forward-facing takedown lights.
- Modular & Always In Stock: Standardized hardware with post-purchase software configuration means the exact configuration you need is ready to ship fast.
- Rugged & Reliable: Engineered for real-world fire service use. Durable, field-proven, and backed by FireTech’s reputation for reliability.
Perfect For
- Volunteer Firefighter POVs / Personal Vehicles: Superb for upfitting pickup trucks, SUVs, and daily drivers. Gives volunteers professional, legitimate warning capability without the bulk of full-size apparatus bars.
- Administrative & Command Vehicles: Clean, low-profile install for chief’s cars, command SUVs, and support vehicles.
- Brush Trucks & Utility Vehicles: Ideal for off-road, rural, and wildland response where a compact, versatile bar shines.
- Patrol Cars & Law Enforcement: Configurable for red/blue/white front with appropriate rear patterns.
- General Utility / Work Vehicles: Amber/white configurations with brake/tail/turn functionality for tow trucks, work trucks, and other roadside safety applications.
The Instinct gives you the visibility, versatility, and confidence to do the job right, whether you’re rolling out of the driveway in a POV or running calls in department vehicles. Built by firefighters who get it, for firefighters who live it. No Doubt About It.
• 54” and 48” sizes available
• Dual or tri-color lighthead options
• Sensor for auto-dimming
• 360 degree seamless output that meet and exceed SAE standards
• Headache rack and other mounting options available
• Software programmable
Specifications
INSTINCT Lightbar (all models):
Width × depth: 12.14" × 1.57" (overall length varies; see table)
Power: 12-24V DC
Fuse rating @12V DC: 30A
Mount: Low Profile Feet
Certifications: SAE J845 Class 1, SAE J595 Class 1, CA Title 13, ECE R65 II (TA2/TB2/TR2), ECE R10; CISPR25, ICAO (A)
| Product | Part Number | Colors / configuration | Overall length | Max Amp. @12V DC | Peak Watt. |
|---|---|---|---|---|---|
| INSTINCT 48" LIGHTBAR | RL-INST-48-RBW-RBA | R/B/W front; R/B/A rear | 48" | 19.8A | 253.44W |
| INSTINCT 48" LIGHTBAR | RL-INST-48-AW-AW-STT | A/W with R STT | 48" | 19.8A | 253.44W |
| INSTINCT 54" LIGHTBAR | RL-INST-54-RBW-RBA | R/B/W front; R/B/A rear | 54" | 22A | 281.6W |
| INSTINCT 54" LIGHTBAR | RL-INST-54-AW-AW-STT | A/W with R STT | 54" | 22A | 281.6W |
